Advanced Ultrasound in Diagnosis and Therapy ›› 2025, Vol. 9 ›› Issue (3): 245-253.doi: 10.26599/AUDT.2025.240044
• Review Article • Previous Articles Next Articles
Yang Jiea, Liu Xiaodia, Wang Wenhuia, Liao Mina, Wu Zheb,c, Galeano Julyd, Perez-Buitrago Sandrae, Lu Qianga,*()
Received:
2024-08-23
Revised:
2025-03-04
Accepted:
2025-04-01
Online:
2025-09-30
Published:
2025-10-13
Contact:
Department of Ultrasound, West China Hospital, Sichuan University, Chengdu, 610041, China. e-mail:luqiang@scu.edu.cn(Q L),
Yang Jie, Liu Xiaodi, Wang Wenhui, Liao Min, Wu Zhe, Galeano July, Perez-Buitrago Sandra, Lu Qiang. Therapeutic Focused Ultrasound: Advances in Antitumor Immunotherapy of Solid Tumors. Advanced Ultrasound in Diagnosis and Therapy, 2025, 9(3): 245-253.
Table 1
Overview of described immune effects after T-HIFU in clinical studies"
Cancer | FUS mode | Combined treatment | Parameters | Immunomodulatory effects | References |
Pancreatic carcinoma | HIFU | NA | Frequency: NA Acoustic power: 0.5-1.6 kW Duty cycle: 66% | ↑ NK cells | [ |
Prostate cancer | HIFU | NA | Frequency: 4.0 MHz Acoustic power: 1260-2000 W/cm2 Duty cycle: 100% | ↑Th1 cytokine (IL-2, IFN-γ, TNF-α) ↓Th2 cytokine (IL-4, IL-5, IL-10) | [ |
Breast cancer | HIFU | NA | Frequency: 1.6MHz Acoustic power: 5000-15000 W/cm2 Duty cycle: 100% | ↑ B cells, and NK cells ↑ HSP 70, ↑ DCs, macrophages ↑ CD3+, CD4+, CD8+, D4+/CD8+ T cells ↑ Fas ligand+, granzyme+ and perforin+ | [ |
Solid tumor (HCC, RCC) | HIFU | NA | Frequency: 0.8 MHz Acoustic power: 5000-20000 W/cm2 Duty cycle: 100% | ↑ CD4+ and the CD4+/CD8+ T cells ↓ VEGF、TGF-β1、TGF-β2 | [ |
Table 2
Overview of described immune effects after T-HIFU in preclinical studies"
Cancer | FUS mode | Combined treatment | Parameters | Immunomodulatory effects | References |
Colon cancer | HIFU | pFAR4-IL-12 | Frequency: 1.1-4.0 MHz Acoustic power: −6.7 MPa~ −10.78 MPa, 5-50 W Duty cycle: 20-100% | ↑ ATP, HSP60 ↑ DCs maturation and M1 macrophages ↑ CTLs, CD8+ T cells, memory T cells ↓ CD4+Foxp3+ T cells ↑ IFN-γ, TNF-α, IL-12 cytokines | [ |
Breast cancer | HIFU; HIFU+MnO2 HIFU+ nanobubble | TLR9 agonist; ICIs | Frequency: 1.0-9.5 MHz Acoustic power: −3.1 MPa; 5-120 W Duty cycle: 100% | ↓ MDSCs ↑ DCs maturation; ↑↓ macrophage ↑ CD8+ and CD4+ T cells ↑ IFN-γ, IL-12, TNF-α, PD-L1, IL-4 and IgG1 cytokines; ↑↓ IL-10 cytokines | [ |
HCC | HIFU; HIFU-activated T lymphocytes; Tumor debris from HIFU ablation; | NA | Frequency: 9.5 MHz Acoustic power: 5 W Duty cycle: 100% | ↑ DCs maturation; ↑ CD8+ T cells ↑ IFN-γ, IL-12, TNF-αcytokines; | [ |
Melanoma | HIFU | a-CD40 | requency: 1.5-9.3 MHz Acoustic power: −3.1 MPa~−6.7 MPa, 4.5-6 W Duty cycle: 50-100% | ↑ DCs maturation, M1 macrophage ↑ CTLs ↑ IFN-γ, TNF-α, Granzyme B+, IL-12 cytokines ↓ PD-1 expression ↓ miR-134 on CD86 | [ |
Glioblastoma | HIFU | GEVs; | Frequency: 1.1-3.5 MHz Acoustic power: 5 W; −3.1MPa Duty cycle: 100% | ↑ DCs maturation, altered macrophage polarization ↑ CD8+, CD4+ T cells ↑ IL-12p70 production ↑ Nlrp3, Jun, Mefv, IL-6 and IL-1β | [ |
Lymphoma | HIFU | NA | Frequency: 3.0 MHz Acoustic power: 35-37 W (140-148 J) | ↑ DCs maturation, ↑ PD-L1 expression | [ |
Sarcoma | HIFU | NA | Frequency: 3.0 MHz Acoustic power: 10 W/cm2 Duty cycle: 100% | ↑ Macrophages and lymphocytes | [ |
Table 3
Overview of described immune effects after M-HIFU in preclinical studies"
Cancer | FUS mode | Combined treatment | Parameters | Immunomodulatory effects | References |
Colon cancer | mHIFU | NA | Frequency: 1.1-3.3 MHz Acoustic power: −10.7~−12 MPa Duty cycle: 2-3% | ↑ ATP, HSP60 ↑ DCs maturation ↑ CTLs, ↑ IFN-γ | [ |
Prostate cancer | Boiling histotripsy | Surgery | Frequency: 3.3 MHz Acoustic power: −10 MPa Duty cycle: 2% | ↓ STAT3 activation ↑ DCs maturation ↑ CD8+ T cells; ↓CD4+ Foxp3+ T cells ↑ IFN-γ cytokines | [ |
Breast cancer | mHIFU pHIFU Histotripsy | ICIs | Frequency: 1.15-2 MHz Acoustic power: −1~−53 MPa, 200 W Duty cycle: 1-10% | TNF-induced necrosis signaling pathway and ICD effects ↑↓ MDSCs, M1, M2 macrophages ↑ CRT, HSP70, HMGB1 ↑ DCs maturation ↑ CD8+ and CD4+ T cells ↑ IFN-γ, IL-1α, IL-1β, IL-18, IL-8 cytokines; ↓ TNF-β cytokines | [ |
HCC | Histotripsy | ICIs | Frequency: 1.0 MHz Acoustic power: > −30 MPa Duty cycle: 1-2% | Necroptotic immunogenic cell death (↑pMLKL/pRIPK3, 4-HNE) ↑ ATP, HMGB1, CRT ↑ NK cells ↑DCs maturation ↑ CD8+ T cells ↓ CD4+ Foxp3+ T cells | [ |
Melanoma | Histotripsy | α-CD40 | Frequency: 1.0-3.28 MHz Acoustic power: −6~−30 MPa, 450 W Duty cycle: 1-10% | ↓ NK cells ↑Granulocytes, neutrophils, monocytes, B cells ↑ DCs, macrophages (both M1 and M2) ↑ Th cells, Tcyt, CD4+, granzyme B+ CD8+, CD8+ T cells ↑ IFN-γ cytokines; ↓ IL-10 cytokines | [ |
Glioblastoma | pHIFU+ nanobubble; Histotripsy | ICIs | Frequency: 1.1-1.5 MHz Acoustic power: −14 MPa Duty cycle: ~2% | ↑NK cells ↑ DAMPs (HMGB1, CRT) ↑ CD45+, CD8+ T cells ↓ CD4+ Foxp3+ T cells ↑ IL-2, IFN-γ cytokines; ↓ IL-10, and VEGF-α cytokines | [ |
Pancreatic cancer | pHIFU Histotripsy | Chemotherapy; ICIs; Oncolytic reovirus; α-CD40 | Frequency: 1.5 MHz Acoustic power: −16.5~ −21 MPa Duty cycle: 1% | ↑ Neutrophils ↑ HMGB1, Granzyme-B+ ↑↓ Macrophages ↑ IFN-γ+CD8+ T cells, IFN-γ+CD8+/ CD4+ Foxp3+ T cells ↓ CD4+ Foxp3+ T cells | [ |
RCC | Histotripsy | NA | Frequency: 1.5 MHz Acoustic power: −17~−20 MPa Duty cycle: 1% | ↑ HMGB1 ↑ TNF-α, IL-10, and IL-6 cytokines | [ |
Table 4
Immunomodulatory effects of therapeutic FUS in solid tumors"
Aspect | Immune response* | T-HIFU | M-HIFU |
Innate immune response | DAMPs released | ↑ ATP, HSP 60/70 | ↑ ATP, HSP 60/70, HMGB1, CRT |
NK cells, Neutrophils, Granulocytes, monocytes, B cells | ↑ B cells, NK cells | ↑ NK cells, granulocytes, neutrophils, monocytes, B cells | |
APC | ↑ DC maturation ↑↓ M1/M2 macrophages | ↑ DC maturation ↑↓ M1/M2 macrophages | |
Cytokines | ↑ IL-2, IFN-γ, TNF-α ↓ VEGF、TGF-β1、TGF-β2 | ↑ IFN-γ, IL-1α, IL-1β, IL-18, IL-8, IL-2 ↓ IL-10, VEGF-α, TNF-β | |
Adaptive immune response | CD4+, CD8+ T cells | ↑ CD3+, CD4+ and the CD4+/CD8+ T cells | ↑ CD3+, CD4+ and the CD4+/CD8+ T cells |
Cytokines | ↑ Fas ligand+, granzyme+ and perforin+ | ↑ Fas ligand+, granzyme+ and perforin+, IFN-γ+CD8+ T cells, granzyme B+ CD8+ T cells | |
Immunosuppressive microenvironment | Treg, MDSC activity | ↓ Treg, MDSC activity | ↓ Treg, MDSC activity |
Other effects | - | NA | ↑ TNF-induced necrosis signaling pathway, ICD, Necroptosis ↓ STAT3 activation |
Synergistic effects | ICIs | synergistic anti-tumor effects | synergistic anti-tumor effects |
Future direction | - | Stronger immune response | Clinical application and safety |
[1] | Siegel RL, Giaquinto AN, Jemal A. Cancer statistics, 2024. CA Cancer J Clin 2024; 74: 12-49. |
[2] | Binnewies M, Roberts EW, Kersten K, Chan V, Fearon DF, Merad M, et al. Understanding the tumor immune microenvironment (TIME) for effective therapy. Nat Med 2018; 24: 541-550. |
[3] | Chang C-H, Qiu J, O’Sullivan D, Buck MD, Noguchi T, Curtis JD, et al. Metabolic competition in the tumor microenvironment is a driver of cancer progression. Cell 2015; 162: 1229-1241. |
[4] | Kim S-D, Kwag E-B, Yang M-X, Yoo H-S. Efficacy and safety of ginger on the side effects of chemotherapy in breast cancer patients: systematic review and meta-analysis. Int J Mol Sci 2022; 23: 11267. |
[5] | Casadei-Gardini A, Scartozzi M, Tada T, Yoo C, Shimose S, Masi G, et al. Lenvatinib versus Sorafenib in first-line treatment of unresectable hepatocellular carcinoma: an inverse probability of treatment weighting analysis. Liver International 2021; 41: 1389-1397. |
[6] | Keilson JM, Knochelmann HM, Paulos CM, Kudchadkar RR, Lowe MC. The evolving landscape of immunotherapy in solid tumors. J Surg Oncol 2021; 123: 798-806. |
[7] | Schizas D, Charalampakis N, Kole C, Economopoulou P, Koustas E, Gkotsis E, et al. Immunotherapy for pancreatic cancer: A 2020 update. Cancer Treat Rev 2020; 86: 102016. |
[8] | Brown M, Farquhar-Smith P, Williams J, Ter Haar G, Desouza N. The use of high-intensity focused ultrasound as a novel treatment for painful conditions—a description and narrative review of the literature. BJA: British Journal of Anaesthesia 2015; 115: 520-530. |
[9] | Hoogenboom M, Eikelenboom D, den Brok MH, Heerschap A, Futterer JJ, Adema GJ. Mechanical high-intensity focused ultrasound destruction of soft tissue: working mechanisms and physiologic effects. Ultrasound Med Biol 2015; 41: 1500-1517. |
[10] | Keisling SM, Singh S, Chavez CG, Kumar M, Karunakaran C, Guha C. Neoadjuvant acoustic immune priming with low-intensity focused ultrasound and doxil for in situ tumor vaccination in a murine triple-negative breast cancer model. Journal of the American College of Surgeons 2021; 233: S250-S251. |
[11] | Ashar H, Ranjan A. Immunomodulation and targeted drug delivery with high intensity focused ultrasound (HIFU): Principles and mechanisms. Pharmacol Ther 2023; 244: 108393. |
[12] | Mekers V, de Visser M, Suijkerbuijk K, Bos C, Moonen C, Deckers R, et al. Mechanical HIFU and immune checkpoint inhibition: toward clinical implementation. Int J Hyperthermia 2024; 41: 2430333. |
[13] | Hancock H, Dreher MR, Crawford N, Pollock CB, Shih J, Wood BJ, et al. Evaluation of pulsed high intensity focused ultrasound exposures on metastasis in a murine model. Clin Exp Metastasis 2009; 26: 729-738. |
[14] | ter Haar GR. High intensity focused ultrasound for the treatment of tumors. Echocardiography 2001; 18: 317-322. |
[15] | Wang X, Sun J. High-intensity focused ultrasound in patients with late-stage pancreatic carcinoma. Chin Med J (Engl) 2002; 115: 1332-1335. |
[16] | Wu F, Wang ZB, Lu P, Xu ZL, Chen WZ, Zhu H, et al. Activated anti-tumor immunity in cancer patients after high intensity focused ultrasound ablation. Ultrasound Med Biol 2004; 30: 1217-1222. |
[17] | Kramer G, Steiner GE, Gröbl M, Hrachowitz K, Reithmayr F, Paucz L, et al. Response to sublethal heat treatment of prostatic tumor cells and of prostatic tumor infiltrating T-cells. Prostate 2004; 58: 109-120. |
[18] | Zhou Q, Zhu X-Q, Zhang J, Xu Z-L, Lu P, Wu F. Changes in circulating immunosuppressive cytokine levels of cancer patients after high intensity focused ultrasound treatment. Ultrasound Med Biol 2008; 34: 81-87. |
[19] | Lu P, Zhu X-Q, Xu Z-L, Zhou Q, Zhang J, Wu F. Increased infiltration of activated tumor-infiltrating lymphocytes after high intensity focused ultrasound ablation of human breast cancer. Surgery 2009; 145: 286-293. |
[20] | Zhu X-Q, Lu P, Xu Z-L, Zhou Q, Zhang J, Wang Z-B, et al. Alterations in immune response profile of tumor-draining lymph nodes after high-intensity focused ultrasound ablation of breast cancer patients. Cells 2021; 10: 3346. |
[21] | Xu Z-L, Zhu X-Q, Lu P, Zhou Q, Zhang J, Wu F. Activation of tumor-infiltrating antigen presenting cells by high intensity focused ultrasound ablation of human breast cancer. Ultrasound Med Biol 2009; 35: 50-57. |
[22] | Xia J-Z, Xie F-L, Ran L-F, Xie X-P, Fan Y-M, Wu F. High-intensity focused ultrasound tumor ablation activates autologous tumor-specific cytotoxic T lymphocytes. Ultrasound Med Biol 2012; 38: 1363-1371. |
[23] | Do HD, Marie C, Bessoles S, Dhotel H, Seguin J, Larrat B, et al. Combination of thermal ablation by focused ultrasound, pFAR4-IL-12 transfection and lipidic adjuvant provide a distal immune response. Explor Target Antitumor Ther 2022; 3: 398-413. |
[24] | Yuan S-M, Li H, Yang M, Zha H, Sun H, Li X-R, et al. High intensity focused ultrasound enhances anti-tumor immunity by inhibiting the negative regulatory effect of miR-134 on CD86 in a murine melanoma model. Oncotarget 2015; 6: 37626-37637. |
[25] | van den Bijgaart RJE, Mekers VE, Schuurmans F, Raaijmakers TK, Wassink M, Veltien A, et al. Mechanical high-intensity focused ultrasound creates unique tumor debris enhancing dendritic cell-induced T cell activation. Frontiers in immunology 2022; 13: 1038347. |
[26] | Deng J, Zhang Y, Feng J, Wu F. Dendritic cells loaded with ultrasound-ablated tumour induce in vivo specific antitumour immune responses. Ultrasound Med Biol 2010; 36: 441-448. |
[27] | Kuai X, Zhu Y, Yuan Z, Wang S, Lin L, Ye X, et al. Perfluorooctyl bromide nanoemulsions holding MnO2 nanoparticles with dual-modality imaging and glutathione depletion enhanced HIFU-eliciting tumor immunogenic cell death. Acta Pharm Sin B 2022; 12: 967-981. |
[28] | Liu F, Hu Z, Qiu L, Hui C, Li C, Zhong P, et al. Boosting high-intensity focused ultrasound-induced anti-tumor immunity using a sparse-scan strategy that can more effectively promote dendritic cell maturation. J Transl Med 2010; 8: 1-12. |
[29] | Zhang Y, Deng J, Feng J, Wu F. Enhancement of antitumor vaccine in ablated hepatocellular carcinoma by high-intensity focused ultrasound. World journal of gastroenterology: WJG 2010; 16: 3584. |
[30] | Xiong J, Jiang B, Luo Y, Zou J, Gao X, Xu D, et al. Multifunctional nanoparticles encapsulating Astragalus polysaccharide and gold nanorods in combination with focused ultrasound for the treatment of breast cancer. Int J Nanomedicine 2020; 4151-4169. |
[31] | Sheybani ND, Batts AJ, Mathew AS, Thim EA, Price RJ. Focused ultrasound hyperthermia augments release of glioma-derived extracellular vesicles with differential immunomodulatory capacity. Theranostics 2020; 10: 7436-7447. |
[32] | Hu Z, Yang XY, Liu Y, Morse MA, Lyerly HK, Clay TM, et al. Release of endogenous danger signals from HIFU-treated tumor cells and their stimulatory effects on APCs. Biochem Biophys Res Commun 2005; 335: 124-131. |
[33] | Hu Z, Yang XY, Liu Y, Sankin GN, Pua EC, Morse MA, et al. Investigation of HIFU-induced anti-tumor immunity in a murine tumor model. J Transl Med 2007; 5: 1-11. |
[34] | Li C, Lu Y, Cheng L, Zhang X, Yue J, Liu J. Combining mechanical high-intensity focused ultrasound ablation with chemotherapy for augmentation of anticancer immune responses. Mol Pharm 2021; 18: 2091-2103. |
[35] | Han X, Wang R, Xu J, Chen Q, Liang C, Chen J, et al. In situ thermal ablation of tumors in combination with nano-adjuvant and immune checkpoint blockade to inhibit cancer metastasis and recurrence. Biomaterials 2019; 224. |
[36] | Silvestrini MT, Ingham ES, Mahakian LM, Kheirolomoom A, Liu Y, Fite BZ, et al. Priming is key to effective incorporation of image-guided thermal ablation into immunotherapy protocols. JCI Insight 2017; 2: e90521. |
[37] | Abe S, Nagata H, Crosby EJ, Inoue Y, Kaneko K, Liu CX, et al. Combination of ultrasound-based mechanical disruption of tumor with immune checkpoint blockade modifies tumor microenvironment and augments systemic antitumor immunity. Journal for immunotherapy of cancer 2022; 10: e003717. |
[38] | Yunna C, Mengru H, Lei W, Weidong C. Macrophage M1/M2 polarization. Eur J Pharmacol 2020; 877: 173090. |
[39] | Shapouri-Moghaddam A, Mohammadian S, Vazini H, Taghadosi M, Esmaeili SA, Mardani F, et al. Macrophage plasticity, polarization, and function in health and disease. J Cell Physiol 2018; 233: 6425-6440. |
[40] | Fite BZ, Wang J, Kare AJ, Ilovitsh A, Chavez M, Ilovitsh T, et al. Immune modulation resulting from MR-guided high intensity focused ultrasound in a model of murine breast cancer. Scientific Reports 2021; 11: 927. |
[41] | Chida S, Okada K, Suzuki N, Komori C, Shimada Y. Infiltration by macrophages and lymphocytes in transplantable mouse sarcoma after irradiation with high-intensity focused ultrasound. Anticancer research 2009; 29: 3877-3882. |
[42] | Singh MP, Sethuraman SN, Ritchey J, Fiering S, Guha C, Malayer J, et al. In-situ vaccination using focused ultrasound heating and anti-CD-40 agonistic antibody enhances T-cell mediated local and abscopal effects in murine melanoma. Int J Hyperthermia 2019; 36: 64-73. |
[43] | Nam GH, Pahk KJ, Jeon S, Park HJ, Kim GB, Oh SJ, et al. Investigation of the potential immunological effects of boiling histotripsy for cancer treatment. Advanced Therapeutics 2020; 3: 1900214. |
[44] | Chavez M, Silvestrini MT, Ingham ES, Fite BZ, Mahakian LM, Tam SM, et al. Distinct immune signatures in directly treated and distant tumors result from TLR adjuvants and focal ablation. Theranostics 2018; 8: 3611-3628. |
[45] | Tang R, He H, Lin X, Wu N, Wan L, Chen Q, et al. Novel combination strategy of high intensity focused ultrasound (HIFU) and checkpoint blockade boosted by bioinspired and oxygen-supplied nanoprobe for multimodal imaging-guided cancer therapy. Journal for immunotherapy of cancer 2023; 11: e006226. |
[46] | Artyomov MN, Sergushichev A, Schilling JD. Integrating immunometabolism and macrophage diversity. Semin Immunol 2016; 28: 417-424. |
[47] | Ramachandran M, Dimberg A, Essand M. The cancer-immunity cycle as rational design for synthetic cancer drugs: Novel DC vaccines and CAR T-cells. Semin Cancer Biol 2017; 45: 23-35. |
[48] | Labanieh L, Majzner RG, Mackall CL. Programming CAR-T cells to kill cancer. Nature biomedical engineering 2018; 2: 377-391. |
[49] | Berrien-Elliott MM, Jacobs MT, Fehniger TA. Allogeneic natural killer cell therapy. Blood 2023; 141: 856-868. |
[50] | Monberg TJ, Borch TH, Svane IM, Donia M. TIL therapy: facts and hopes. Clinical Cancer Research 2023; 29: 3275-3283. |
[51] | Rosenberg SA, Restifo NP. Adoptive cell transfer as personalized immunotherapy for human cancer. Science 2015; 348: 62-68. |
[52] | Ran L-F, Xie X-P, Xia J-Z, Xie F-L, Fan Y-M, Wu F. Specific antitumour immunity of HIFU-activated cytotoxic T lymphocytes after adoptive transfusion in tumour-bearing mice. International Journal of Hyperthermia 2016; 32: 204-210. |
[53] | Ran L-F, Xie X-P, Xia J-Z, Xie F-L, Fan Y-M, Wu F. T-lymphocytes from focused ultrasound ablation subsequently mediate cellular antitumor immunity after adoptive cell transfer immunotherapy. Frontiers in immunology 2023; 14: 1155229. |
[54] | Wang J, Huang CH, Echeagaray OH, Amirfakhri S, Blair SL, Trogler WC, et al. Microshell Enhanced Acoustic Adjuvants for Immunotherapy in Glioblastoma. Advanced Therapeutics 2019; 2: 839-848. |
[55] | Schade GR, Wang Y-N, D'Andrea S, Hwang JH, Liles WC, Khokhlova TD. Boiling histotripsy ablation of renal cell carcinoma in the eker rat promotes a systemic inflammatory response. Ultrasound Med Biol 2019; 45: 137-147. |
[56] | Khokhlova TD, Wang Y-N, Son H, Totten S, Whang S, Ha Hwang J. Chronic effects of pulsed high intensity focused ultrasound aided delivery of gemcitabine in a mouse model of pancreatic cancer. Ultrasonics 2023; 132: 106993. |
[57] | Stepanechko M, Gamache A, Padilla F, Nemshick M, Kitelinger L, Conarroe C, et al. Single treatment boiling histotripsy focused ultrasound ablation neither negates nor enhances the activity of α-CD40 in a pancreatic cancer model. IEEE Trans Biomed Eng 2025; PP. |
[58] | Glickstein B, Bismuth M, Gattegno R, Bercovici T, Shaul O, Aronovich R, et al. Volumetric nanodroplet-enhanced ultrasound surgery combined with immune checkpoint inhibition as a cancer therapy platform. Small 2025; 21: e2411474. |
[59] | Thim EA, Kitelinger LE, Rivera-Escalera F, Mathew AS, Elliott MR, Bullock TN, et al. Focused ultrasound ablation of melanoma with boiling histotripsy yields abscopal tumor control and antigen-dependent dendritic cell activation. bioRxiv 2024; 14: 1647-1661. |
[60] | Mouratidis PXE, Costa M, Rivens I, Repasky EE, Ter Haar G. Pulsed focused ultrasound can improve the anti-cancer effects of immune checkpoint inhibitors in murine pancreatic cancer. J R Soc Interface 2021; 18: 20210266. |
[61] | Qu S, Worlikar T, Felsted AE, Ganguly A, Beems MV, Hubbard R, et al. Non-thermal histotripsy tumor ablation promotes abscopal immune responses that enhance cancer immunotherapy. Journal for immunotherapy of cancer 2020; 8: e000200. |
[62] | Eranki A, Srinivasan P, Ries M, Kim A, Lazarski CA, Rossi CT, et al. High-intensity focused ultrasound (HIFU) triggers immune sensitization of refractory murine neuroblastoma to checkpoint inhibitor therapy. Clin Cancer Res 2020; 26: 1152-1161. |
[63] | Pahk KJ, Shin C-H, Bae IY, Yang Y, Kim S-H, Pahk K, et al. Boiling histotripsy-induced partial mechanical ablation modulates tumour microenvironment by promoting immunogenic cell death of cancers. Scientific reports 2019; 9: 9050. |
[64] | Pepple AL, Guy JL, McGinnis R, Felsted AE, Song B, Hubbard R, et al. Spatiotemporal local and abscopal cell death and immune responses to histotripsy focused ultrasound tumor ablation. Frontiers in immunology 2023; 14: 1012799. |
[65] | Hendricks-Wenger A, Sereno J, Gannon J, Zeher A, Brock RM, Beitel-White N, et al. Histotripsy ablation alters the tumor microenvironment and promotes immune system activation in a subcutaneous model of pancreatic cancer. IEEE Trans Ultrason Ferroelectr Freq Control 2021; 68: 2987-3000. |
[66] | Aydin O, Chandran P, Lorsung RR, Cohen G, Burks SR, Frank JA. The proteomic effects of pulsed focused ultrasound on tumor microenvironments of murine melanoma and breast cancer models. Ultrasound Med Biol 2019; 45: 3232-3245. |
[67] | Cohen G, Chandran P, Lorsung RM, Aydin O, Tomlinson LE, Rosenblatt RB, et al. Pulsed-focused ultrasound slows B16 melanoma and 4T1 breast tumor growth through differential tumor microenvironmental changes. Cancers (Basel) 2021; 13: 1546. |
[68] | Worlikar T, Zhang M, Ganguly A, Hall TL, Shi J, Zhao L, et al. Impact of histotripsy on development of intrahepatic metastases in a rodent liver tumor model. Cancers (Basel) 2022; 14: 1612. |
[69] | Mouratidis P, Ferreira RC, Anbalagan S, Chauhan R, Rivens I, Ter Haar G. Transcriptomic profiling of the immune response in orthotopic pancreatic tumours exposed to combined boiling histotripsy and oncolytic reovirus treatment. Pharmaceutics 2025; 17: 949. |
[70] | Wilky BA. Immune checkpoint inhibitors: The linchpins of modern immunotherapy. Immunological reviews 2019; 290: 6-23. |
[71] | Cheng A-L, Hsu C, Chan SL, Choo S-P, Kudo M. Challenges of combination therapy with immune checkpoint inhibitors for hepatocellular carcinoma. J Hepatol 2020; 72: 307-319. |
[72] | Donisi C, Puzzoni M, Ziranu P, Lai E, Mariani S, Saba G, et al. Immune checkpoint inhibitors in the treatment of HCC. Front Oncol 2020; 10: 601240. |
[73] | Federico P, Petrillo A, Giordano P, Bosso D, Fabbrocini A, Ottaviano M, et al. Immune checkpoint inhibitors in hepatocellular carcinoma: Current status and novel perspectives. Cancers (Basel) 2020; 12: 3025. |
[74] | Liu Z, Liu X, Liang J, Liu Y, Hou X, Zhang M, et al. Immunotherapy for hepatocellular carcinoma: Current status and future prospects. Frontiers in immunology 2021; 12: 765101. |
[75] | Wu N, Cao Y, Liu Y, Zhou Y, He H, Tang R, et al. Low-intensity focused ultrasound targeted microbubble destruction reduces tumor blood supply and sensitizes anti-PD-L1 immunotherapy. Front Bioeng Biotechnol 2023; 11: 1173381. |
[76] | Singh MP, Sethuraman SN, Miller C, Malayer J, Ranjan A. Boiling histotripsy and in-situ CD40 stimulation improve the checkpoint blockade therapy of poorly immunogenic tumors. Theranostics 2021; 11: 540-554. |
[77] | Liu Q, Liao Q, Zhao Y. Chemotherapy and tumor microenvironment of pancreatic cancer. Cancer cell international 2017; 17: 1-17. |
[78] | Bandyopadhyay S, Quinn TJ, Scandiuzzi L, Basu I, Partanen A, Tomé WA, et al. Low-intensity focused ultrasound induces reversal of tumor-induced T cell tolerance and prevents immune escape. The Journal of Immunology 2016; 196: 1964-1976. |
[79] | Huang X, Yuan F, Liang M, Lo H-W, Shinohara ML, Robertson C, et al. M-HIFU inhibits tumor growth, suppresses STAT3 activity and enhances tumor specific immunity in a transplant tumor model of prostate cancer. PLoS One 2012; 7: e41632. |
[80] | Ektate K, Munteanu MC, Ashar H, Malayer J, Ranjan A. Chemo-immunotherapy of colon cancer with focused ultrasound and Salmonella-laden temperature sensitive liposomes (thermobots). Sci Rep 2018; 8: 13062. |
[81] | Yang J, Liao M, Wu Z, Liu X, Zheng Z, Wang W, et al. Perfluorohexane nanodroplet-assisted mechanical high intensity focused ultrasound cavitation: A strategy for hepatocellular carcinoma treatment. Acta Biomater 2025; 195: 297-308. |
[1] | Ruiqing Liu, MD, Yaqiong Li, PhD, Bing Mao, MD, Na Li, PhD, Shaobo Duan, MD, Zhiyang Chang, MS, Ye Zhang, MS, Shuaiyang Wang, MS, Lianzhong Zhang, MD. Focal Ablation Therapy for Prostate Cancer: A Literature Review [J]. Advanced Ultrasound in Diagnosis and Therapy, 2020, 4(4): 308-314. |
